DxBarGauge.StartValue Property

Specifies the bar gauge’s start value.

Namespace: DevExpress.Blazor

Assembly: DevExpress.Blazor.v25.1.dll

NuGet Package: DevExpress.Blazor

Declaration

[DefaultValue(0)]
[Parameter]
public double StartValue { get; set; }

Property Value

Type	Default	Description
Double	0	The bar gauge’s start value.

Remarks

Specify StartValue and EndValue properties to define the bar gauge’s scale range. The following code snippet changes the range of visible values and renders bars based on the range:

<DxBarGauge Width="100%"
            Height="500px"
            StartValue="-5"
            EndValue="5"
            Values="@Values">
    @* ... *@
</DxBarGauge>

@code {
    double[] Values = new double[] { -2.13, 1.48, -3.09, 4.52, 4.9, 3.9 };
    // ...
}
