DxPieChartSeries<T, TArgument, TValue> Class

Defines a pie or donut series.

Namespace: DevExpress.Blazor

Assembly: DevExpress.Blazor.v23.2.dll

NuGet Package: DevExpress.Blazor

Declaration

public class DxPieChartSeries<T, TArgument, TValue> :
    DxComplexSettingsComponent<DxPieChartSeries<T, TArgument, TValue>, IPieChartSeriesModel>,
    IModelProvider<ChartSeriesLabelModel>,
    IModelProvider<ChartSeriesLegendItemModel>,
    IPieChartSeries,
    IChartSeriesBase

Type Parameters

Name	Description
T	The type of data.
TArgument	The type of arguments.
TValue	The type of values.

Remarks

The following image demonstrates a pie chart sample:

Use the Pie Chart’s Data property to specify an IEnumerable<T> data source. The chart should contain at least one series to display data. Use the following series properties to bind the data source fields to the series:

• ArgumentField: specifies the data source field that contains arguments for chart points.
• ValueField: specifies the data source field that contain values for chart points.

For a sample data source, refer to our GitHub repository.

Razor

<DxPieChart Data="@SalesData">
    <DxChartTitle Text="Total Sales" />
    <DxChartLegend VerticalAlignment="VerticalEdge.Bottom" Position="RelativePosition.Outside" />
    <DxPieChartSeries ValueField="@((SaleInfo i) => i.Amount)"
                      ArgumentField="@(i => i.City)"
                      SummaryMethod="Enumerable.Sum">
        <DxChartSeriesLabel Visible="true" />
    </DxPieChartSeries>
</DxPieChart>

@code {
    IEnumerable<SaleInfo> SalesData;

    protected override async Task OnInitializedAsync() {
        SalesData = (await Sales.GetSalesAsync()).Where(x => x.Country == "United States");
    }
}

SaleInfo

using System;

public class SaleInfo {
    public int OrderId { get; set; }
    public string Region { get; set; }
    public string Country { get; set; }
    public string City { get; set; }
    public int Amount { get; set; }
    public DateTime Date { get; set; }
}

Sales

using System;
using System.Collections.Generic;
using System.Linq;
using System.Threading.Tasks;

public class Sales {
    static IList<SaleInfo> dataSource;
    static Sales() {
        CreateDataSource();
    }

    public static Task<IQueryable<SaleInfo>> GetSalesAsync() {
        return Task.FromResult(dataSource.AsQueryable());
    }

    static void CreateDataSource() {
        dataSource = new List<SaleInfo> {
        new SaleInfo {
                OrderId = 10248,
                Region = "North America",
                Country = "United States",
                City = "New York",
                Amount = 1740,
                Date = DateTime.Parse("2017/01/06")
            },
            new SaleInfo {
                OrderId = 10249,
                Region = "North America",
                Country = "United States",
                City = "Los Angeles",
                Amount = 850,
                Date = DateTime.Parse("2017/01/13")
            },
            new SaleInfo {
                OrderId = 10250,
                Region = "North America",
                Country = "United States",
                City = "Denver",
                Amount = 2235,
                Date = DateTime.Parse("2017/01/07")
            },
            new SaleInfo {
                OrderId = 10251,
                Region = "North America",
                Country = "Canada",
                City = "Vancouver",
                Amount = 1965,
                Date = DateTime.Parse("2017/01/03")
            },
            new SaleInfo {
                OrderId = 10252,
                Region = "North America",
                Country = "Canada",
                City = "Edmonton",
                Amount = 880,
                Date = DateTime.Parse("2017/01/10")
            },
            new SaleInfo {
                OrderId = 10253,
                Region = "South America",
                Country = "Brazil",
                City = "Rio de Janeiro",
                Amount = 5260,
                Date = DateTime.Parse("2017/01/17")
            },
            new SaleInfo {
                OrderId = 10254,
                Region = "South America",
                Country = "Argentina",
                City = "Buenos Aires",
                Amount = 2790,
                Date = DateTime.Parse("2017/01/21")
            },
            new SaleInfo {
                OrderId = 10255,
                Region = "South America",
                Country = "Paraguay",
                City = "Asuncion",
                Amount = 3140,
                Date = DateTime.Parse("2017/01/01")
            },
            new SaleInfo {
                OrderId = 10256,
                Region = "Europe",
                Country = "United Kingdom",
                City = "London",
                Amount = 6175,
                Date = DateTime.Parse("2017/01/24")
            },
            new SaleInfo {
                OrderId = 10257,
                Region = "Europe",
                Country = "Germany",
                City = "Berlin",
                Amount = 4575,
                Date = DateTime.Parse("2017/01/11")
            },
            // ...
    };
    }
}

Run Demo: Charts - Pie Series

Implements

IComponent

IHandleEvent

IHandleAfterRender

IDisposable

IPieChartSeries

IChartSeriesBase

Inheritance

Object

ComponentBase

DxSettingsComponent<DevExpress.Blazor.Internal.IPieChartSeriesModel>

DxComplexSettingsComponent<DxPieChartSeries<T, TArgument, TValue>, DevExpress.Blazor.Internal.IPieChartSeriesModel>

DxPieChartSeries<T, TArgument, TValue>
