TreeListGridlines Enum

Lists gridline visibility options in the DxTreeList component.

Namespace: DevExpress.Blazor

Assembly: DevExpress.Blazor.Grid.v26.1.dll

Declaration

[Flags]
public enum TreeListGridlines

Members

Name	Description
None	All gridlines are invisible.
Horizontal	Horizontal gridlines are visible.
Vertical	Vertical gridlines are visible.
Outside	Component borders are visible.
All	All gridlines are visible.

Related API Members

The following properties accept/return TreeListGridlines values:

• DxTreeList.GridlinesVisible
• ITreeList.GridlinesVisible

Remarks

The following example hides horizontal lines:

<DxTreeList Data="TreeListData"
            KeyFieldName="ID"
            ParentKeyFieldName="RegionID"
            GridlinesVisible="TreeListGridlines.Vertical | TreeListGridlines.Outside">
    <Columns>
        <DxTreeListCommandColumn Width="150px" />
        <DxTreeListDataColumn FieldName="Region" />
        <DxTreeListDataColumn FieldName="MarchSales" DisplayFormat="c0" />
        <DxTreeListDataColumn FieldName="SeptemberSales" DisplayFormat="c0" />
        <DxTreeListDataColumn FieldName="MarchChange" DisplayFormat="p2" />
        <DxTreeListDataColumn FieldName="SeptemberChange" DisplayFormat="p2" />
        <DxTreeListDataColumn FieldName="MarketShare" DisplayFormat="p0" />
    </Columns>
</DxTreeList>
