DxSchedulerSourceObjectContainer.SourceObject Property

A data source object to which a Scheduler item is bound.

Namespace: DevExpress.Blazor

Assembly: DevExpress.Blazor.v25.2.dll

NuGet Package: DevExpress.Blazor

Declaration

public object SourceObject { get; }

Property Value

Type	Description
Object	The data source object.

Remarks

You can use the SourceObject property to access the target appointment’s source object when you manage appointments in code.

The following code snippet does the following:

• Creates a DxSchedulerDataStorage object, sets its AppointmentsSource to null.
• Assigns the created data storage object to the Scheduler’s DataStorage property.
• In the OnInitialized lifecycle method, creates a new DbContext and loads data from the DbContext to the DxSchedulerDataStorage.AppointmentsSource property.

• Handles AppointmentInserted, AppointmentUpdated, and AppointmentRemoved events to implement CRUD operations in the Scheduler. To access a target appointment, the SourceObject property is used.

  You can also use AppointmentInserting, AppointmentUpdating, and AppointmentRemoving events to implement CRUD operations. These events fire before modifications are applied to Scheduler’s appointment collection. You can access the database or service and validate that an appointment was in fact inserted/updated/removed. If validation is successful, pass the appointment further. If not, set the event argument’s Cancel property to true and display an error message (the service is unavailable or the appointment conflicts with another appointment in the database).

• Uses the DbContext.Dispose method to track the context for the component lifetime.

@inject IDbContextFactory<MedicsSchedulingContext> MedicsSchedulingContextFactory
@implements IDisposable

<DxScheduler StartDate="@startDate"
             DataStorage="@DataStorage"
             AppointmentUpdated="@AppointmentUpdated"
             AppointmentInserted="@AppointmentInserted"
             AppointmentRemoved="@AppointmentRemoved"
             GroupType="SchedulerGroupType.Resource">
    <DxSchedulerDayView DayCount="1" ShowWorkTimeOnly="true"></DxSchedulerDayView>
    ...
        <Scales>
            <DxSchedulerTimeScale Unit="@SchedulerTimeScaleUnit.Day" UnitCount="1"></DxSchedulerTimeScale>
            <DxSchedulerTimeScale Unit="@SchedulerTimeScaleUnit.Hour" UnitCount="2"></DxSchedulerTimeScale>
        </Scales>
    </DxSchedulerTimelineView>
</DxScheduler>

@code {
    DateTime startDate { get; set; } = new DateTime(2016, 10, 10);
    MedicsSchedulingContext dbContext { get; set; }

    DxSchedulerDataStorage DataStorage = new DxSchedulerDataStorage() {
            AppointmentsSource = null,
            AppointmentMappings = new DxSchedulerAppointmentMappings() {
                Id = "Id",
                Type = "EventType",
                Start = "StartTime",
                End = "EndTime",
                Subject = "Subject",
                AllDay = "AllDay",
                Location = "Location",
                Description = "Description",
                LabelId = "Label",
                StatusId = "Status",
                ResourceId = "MedicId",
                RecurrenceInfo = "RecurrenceInfo"
            },
            ResourcesSource = null,
            ResourceMappings = new DxSchedulerResourceMappings() {
                Id = "Id",
                Caption = "DisplayName"
            }
        };

    protected override void OnInitialized() {
        dbContext = MedicsSchedulingContextFactory.CreateDbContext();
        DataStorage.AppointmentsSource = dbContext.MedicalAppointments.ToList();
        DataStorage.ResourcesSource = dbContext.Medics.ToList();
    }

    void AppointmentInserted(DxSchedulerAppointmentItem e) {
        dbContext.Add(e.SourceObject);
        dbContext.SaveChanges();
    }

    void AppointmentUpdated(DxSchedulerAppointmentItem e) {
        dbContext.SaveChanges();
    }

    void AppointmentRemoved(DxSchedulerAppointmentItem e) {
        dbContext.Remove(e.SourceObject);
        dbContext.SaveChanges();
    }

    public void Dispose() {
        dbContext?.Dispose();
    }
}

Refer to Bind Scheduler to Remote Data for additional information.

Related GitHub Examples

The following code snippet (auto-collected from DevExpress Examples) contains a reference to the SourceObject property.

Note

The algorithm used to collect these code examples remains a work in progress. Accordingly, the links and snippets below may produce inaccurate results. If you encounter an issue with code examples below, please use the feedback form on this page to report the issue.

C#

blazor-scheduler-custom-form/CS/DxBlazorApplication1/Components/Pages/Index.razor.cs#L83

private async Task OnAppointmentInserted(DxSchedulerAppointmentItem e) {
    if (e.SourceObject is UniversityClass uc) {
        await AptService.InsertAppointmentAsync(uc);
