dxMessageBox(THandle,string,string,Integer,TdxMessageDialogHyperlinkClickDelegate,TdxMessageDialogShowHyperlinkHintDelegate) Method

Invokes a modal message dialog box.

Declaration

function dxMessageBox(AOwnerWndHandle: THandle; const AMessage: string; const ATitle: string; AFlags: Integer; const AHyperlinkClickProc: TdxMessageDialogHyperlinkClickDelegate = nil; const AShowHyperlinkHintProc: TdxMessageDialogShowHyperlinkHintDelegate = nil): Integer;

Parameters

Name	Type	Description
AOwnerWndHandle	THandle	A handle to the owner window of the message box. This parameter allows the dxMessageBox function to emulate the system MessageBox function behavior.
AMessage	string	Message dialog box content. The AMessage parameter value initializes the created form’s Message property. The AMessage parameter supports a set of BBCode-inspired tags that allow you to format message box content. Refer to the Remarks section for the full list of supported formatting tags.
ATitle	string	A message dialog box caption. You can pass an empty string as the ATitle parameter to display the predefined Error caption.
AFlags	Integer	A combination of flags that define available UI elements and message dialog box behavior. Refer to the list of supported flags in the Remarks section.
AHyperlinkClickProc	TdxMessageDialogHyperlinkClickDelegate	Optional. Specifies a procedure that handles a click on a hyperlink within the displayed message. The AHyperlinkClickProc parameter value initializes the HyperlinkClickProc property of the created message dialog box form. You can define a click handler procedure to identify the clicked hyperlink and prevent certain links from being activated. Tip Refer to the TdxMessageDialogHyperlinkClickDelegate procedural type description for detailed information and a code example.
AShowHyperlinkHintProc	TdxMessageDialogShowHyperlinkHintDelegate	Optional. Specifies a procedure that handles a hyperlink hint display event. The AShowHyperlinkHintProc parameter value initializes the ShowHyperlinkHintProc property of the created message dialog box form. You can define a hyperlink hint handler procedure to change the predefined hint message (the hyperlink target URI) depending on certain conditions in your application. Tip Refer to the TdxMessageDialogShowHyperlinkHintDelegate procedural type description for detailed information and a code example.

Returns

Type	Description
Integer	An integer value that indicates the button clicked to close the message box. The dxMessageBox function returns 0 if it fails to invoke a message box. Refer to the list of possible return values in the Remarks section.

Remarks

Call the dxMessageBox function to invoke a generic dialog box with a message and one or more buttons. The created message dialog box has the mdsMessageBox style.

Supported BBCode-Inspired Markup Tags

Text Formatting Attribute	Message Text with Tags	Example
Bold	'[B]DevExpress[/B]'
Italic	'[I]DevExpress[/I]'
Underscore	'[U]DevExpress[/U]'
Strikeout	'[S]DevExpress[/S]'
Subscript	'Dev[Sub]Express[/Sub]'
Superscript	'Dev[Sup]Express[/Sup]'
Custom Font	'Dev[U][Font=Consolas][Size=12]Express[/U][/Font][/Size]'
Color	'[Color=#E67E22]Dev[/Color][Color=Gray]Express[/Color]'
Background Color	'[BackColor=Orange]DevExpress[/BackColor]'
Hyperlink	'[URL=http://www.devexpress.com/]DevExpress[/URL]'
No Parse	'[NOPARSE][B]DevExpress[/B][/NOPARSE]'

Supported Flags

MB_OK

The message box has only the OK button.

MB_RETRYCANCEL

The message box has two buttons: Retry and Cancel.

MB_YESNO

The message box has two buttons: Yes and No.

MB_YESNOCANCEL

The message box has three buttons: Yes, No, and Cancel.

MB_ABORTRETRYIGNORE

The message box has three buttons: Abort, Retry, and Ignore.

MB_OKCANCEL

The message box has two buttons: OK and Cancel.

MB_DEFBUTTON1

Explicitly defines the first button as default. The first button is default unless the MB_DEFBUTTON2, MB_DEFBUTTON3, or MB_DEFBUTTON4 flag is set.

MB_DEFBUTTON2

Sets the second button as default.

MB_DEFBUTTON3

Sets the third button as default.

MB_DEFBUTTON4

Sets the fourth button as default.

MB_ICONWARNING or MB_ICONEXCLAMATION

The message box displays an exclamation sign icon.

MB_ICONERROR, MB_ICONHAND, or MB_ICONSTOP

The message box displays a stop sign button.

MB_ICONINFORMATION or MB_ICONASTERISK

The message box displays the icon that consists of a lowercase i in a circle.

MB_ICONQUESTION

The message box displays a question sign icon.

MB_RTLREADING

The message box changes the direction of message and caption text to right-to-left.

MB_TOPMOST

The message box has the WS_EX_TOPMOST window style.

Returned Values

IDOK

A user clicked the OK button to close the message box.

IDCANCEL

A user clicked the Cancel button to close the message box.

IDABORT

A user clicked the Abort button to close the message box.

IDRETRY

A user clicked the Retry button to close the message box.

IDIGNORE

A user clicked the Ignore button to close the message box.

IDYES

A user clicked the Yes button to close the message box.

IDNO

A user clicked the No button to close the message box.
