    Dockerize an Office File API Application

    • 10 minutes to read

    This tutorial describes how to create and dockerize an ASP.NET Core Web API application that uses the Office File API library to convert Excel and Word documents to HTML.

    View Example: Dockerize an Office File API Application

    Prerequisites

    Create an Application

    1. Create a folder for your project (DocumentConversionWebApi in this example) and open this folder in Visual Studio Code.

    2. Click View → Terminal in the main menu to open the integrated terminal.

    3. Use the dotnet new command to create a new Web API application.

      dotnet new webapi -o DocumentConversionWebApi
cd DocumentConversionWebApi

      The image below shows the created project’s structure.

      Office_WebApi_Project_Structure

      Note

      The ASP.NET Core Web API project template contains WeatherForecast API. Delete the files WeatherForecast.cs and Controllers/WeatherForecastController.cs to remove this API from your project.

    4. Install the DevExpress.Document.Processor and DevExpress.Drawing.Skia NuGet packages as described in the following help topic: Use NuGet Packages to Install Office File API Components.

      Important

      These packages are available as part of the DevExpress Office File API Subscription or DevExpress Universal Subscription.

    5. Implement an API controller to handle HTTP requests. In the Controllers folder, create a ConvertFileController.cs file with the code below. Implement a PostConvertFile action method to handle HTTP POST requests and to convert uploaded files to HTML.

      using Microsoft.AspNetCore.Mvc;
using DevExpress.Spreadsheet;
using DevExpress.XtraRichEdit;
using DevExpress.XtraSpreadsheet.Export;

namespace DocumentConversionWebApi.Controllers {
    [Route("[controller]")]
    [ApiController]
    public class ConvertFileController : ControllerBase {
        [HttpPost]
        public async Task<IActionResult> PostConvertFile(IFormFile file) {
            if (file != null) {
                try {
                    using (var stream = new MemoryStream()) {
                        await file.CopyToAsync(stream);
                        stream.Seek(0, SeekOrigin.Begin);
                        switch (Path.GetExtension(file.FileName)) {
                            case ".rtf":
                            case ".doc":
                            case ".docx":
                            case ".txt":
                            case ".mht":
                            case ".odt":
                            case ".xml":
                            case ".epub":
                            case ".html":
                                return new FileStreamResult(ConvertWordDocument(stream), "text/html");
                            case ".xlsx":
                            case ".xlsm":
                            case ".xlsb":
                            case ".xls":
                            case ".xltx":
                            case ".xltm":
                            case ".xlt":
                            case ".csv":
                                return new FileStreamResult(ConvertSpreadsheetDocument(stream), "text/html");
                        }
                    }
                } catch (Exception e) {
                    return StatusCode(500, e.Message + Environment.NewLine + e.StackTrace);
                }
            }
            return new BadRequestResult();
        }

        Stream ConvertWordDocument(Stream inputStream) {
            using (var wordProcessor = new RichEditDocumentServer()) {
                wordProcessor.LoadDocument(inputStream);
                var resultStream = new MemoryStream();
                wordProcessor.Options.Export.Html.EmbedImages = true;
                wordProcessor.SaveDocument(resultStream, DevExpress.XtraRichEdit.DocumentFormat.Html);
                resultStream.Seek(0, SeekOrigin.Begin);
                return resultStream;
            }
        }
        Stream ConvertSpreadsheetDocument(Stream inputStream) {
            using (var workbook = new Workbook()) {
                workbook.LoadDocument(inputStream);
                var resultStream = new MemoryStream();
                var options = new HtmlDocumentExporterOptions();
                options.EmbedImages = true;
                options.AnchorImagesToPage = true;
                workbook.ExportToHtml(resultStream, options);
                resultStream.Seek(0, SeekOrigin.Begin);
                return resultStream;
            }
        }
    }
}

    Create a Dockerfile

    Create a Dockerfile within your project folder. This file contains instructions required to build a Docker image and deploy it inside a container. Add the following commands to your Dockerfile:

    # Build runtime image
FROM mcr.microsoft.com/dotnet/aspnet:8.0 AS base
WORKDIR /app
EXPOSE 80
EXPOSE 443

# Install the latest version of font libraries
RUN apt update &&\
         apt install -y libc6 libicu-dev libfontconfig1

# (Optional step) Install the ttf-mscorefonts-installer package
# to use Microsoft TrueType core fonts in the application
RUN echo "deb http://ftp.debian.org/debian/ bookworm contrib" >> /etc/apt/sources.list
RUN apt-get update
RUN apt-get install -y ttf-mscorefonts-installer

FROM mcr.microsoft.com/dotnet/sdk:8.0 AS build
ARG BUILD_CONFIGURATION=Release
WORKDIR /src

# Copy the project file
COPY ./DocumentConversionWebApi.csproj ./

# Restore as distinct layers
RUN dotnet restore

# Publish a release
FROM build AS publish
ARG BUILD_CONFIGURATION=Release
RUN dotnet publish "DocumentConversionWebApi.csproj" -c Release -o /app/publish

FROM base AS final
WORKDIR /app
COPY --from=build /app/publish .

# Define the entry point for the application
ENTRYPOINT ["dotnet", "DocumentConversionWebApi.dll"]

    Add a .dockerignore file to your project. Exclude the following folders from the build context to increase build performance:

    bin/
obj/

    Build and Run the Docker Image

    Use the following terminal commands to build and run your Docker image:

    docker build -t documentconversionwebapi .
docker run -d -p 8080:80 documentconversionwebapi

    Test the Application

    This tutorial uses the Thunder Client extension to test the created Web API application.

    1. Install and start Thunder Client in Visual Studio Code. Click New Request to create a new HTTP request to the API endpoint. Select the POST method in the drop-down list and enter the following URL in the input field:

      http://localhost:8080/ConvertFile

      Create a new HTTP POST request

    2. Specify a Request Body for the POST request. Switch to the Body tab and click Form.

      Specify the request body type

    3. Select the Files check box to display the Files section. Enter file as the field name and click Choose File to select a document you wish to convert to HTML.

      Upload a file for conversion

    4. Click Send to upload the selected file to the server and convert this document to HTML.

      Send the request

      The result is displayed on the Response tab. Click Preview to see the generated HTML document.

      Response from the server

    Run Office File API in Minimal / Chiseled Linux Containers

    This section applies to applications deployed in minimal Linux environments such as:

    • .NET chiseled images
    • Distroless containers
    • Images without a package manager
    • Environments without fontconfig or system fonts

    Example base images:

    mcr.microsoft.com/dotnet/aspnet:10.0-noble-chiseled-composite-extra
mcr.microsoft.com/dotnet/sdk:10.0-noble

    Key Differences from Regular Linux Distributions

    Minimal/chiseled images:

    • Do not include fontconfig
    • Do not include /usr/share/fonts
    • Do not allow to install native packages with apt-get
    • Do not support system font discovery

    Due to these limitations, applications must meet the following criteria:

    1. Use the Skia Drawing Engine

    Set the DrawingEngine property to Skia:

    using DevExpress.Drawing;
// ...
Settings.DrawingEngine = DrawingEngine.Skia;

    2. Use SkiaSharp Native Assets Without System Dependencies

    Install the SkiaSharp.NativeAssets.Linux.NoDependencies NuGet package.

    If your dependency graph includes SkiaSharp.NativeAssets.Linux transitively, exclude its runtime assets:

    <ItemGroup>
    <PackageReference Include="SkiaSharp.NativeAssets.Linux"
                      Version="3.119.2" ExcludeAssets="runtime"
                      PrivateAssets="all" />
</ItemGroup>

    This configuration removes the libfontconfig.so.1 dependency.

    3. Include Fonts in the Application

    Minimal and chiseled images cannot discover system fonts. You need to include the required TTF files in the application:

    <ItemGroup>
    <None Include="*.ttf" CopyToPublishDirectory="Always" />
</ItemGroup>

    public static int Main(string[] args) {
    string[] fonts = ["Inter.ttf", "SegoeUI.ttf"];
    string[] fontFiles = [.. fonts.Select(f => Path.Combine(baseDir, f))];
}

    4. Register Fonts Explicitly

    Register fonts manually before you load documents:

    foreach (var fontPath in fontFiles) {
    DXFontRepository.Instance.AddFont(fontPath);
}
// ...
using var richEditDocumentServer = new RichEditDocumentServer();
richEditDocumentServer.LoadDocument(fileName, DocumentFormat.Docx);

    Refer to the following help topic for more information: Load and Use Custom Fonts.

    Example: Chiseled Container (No System Dependencies)

    The following docker file deploys an application to a .NET chiseled image that does not include fontconfig or system fonts:

    FROM mcr.microsoft.com/dotnet/sdk:10.0 AS build
WORKDIR /src
COPY . .
RUN dotnet publish -c Release -o /app

FROM mcr.microsoft.com/dotnet/aspnet:10.0-noble-chiseled-composite-extra
WORKDIR /app
COPY --from=build /app .

ENTRYPOINT ["dotnet", "YourApp.dll"]

    public static int Main(string[] args) {
    //1. Use the Skia Drawing Engine
    Settings.DrawingEngine = DrawingEngine.Skia;

    string fileName = Path.Combine(AppContext.BaseDirectory, "fontTest.docx");

    // 3. Include Fonts in the Application
    string[] fonts = ["Inter.ttf", "SegoeUI.ttf"];
    string[] fontFiles = [.. fonts.Select(f => Path.Combine(baseDir, f))];

    // 4. Register Fonts Explicitly
    foreach (var fp in fontFiles) {
        DXFontRepository.Instance.AddFont(fp);
    }

    using (var wordProcessor = new RichEditDocumentServer()) {
        Document doc = wordProcessor.Document;
        doc.AppendText("This document is generated by Word Processing Document API: Inter font\r\n");
        CharacterProperties cp =
            doc.BeginUpdateCharacters(doc.Paragraphs[0].Range);
        cp.FontName = "Inter";
        doc.EndUpdateCharacters(cp);
        doc.AppendText("This document is generated by Word Processing Document API: NotoSans font");
        CharacterProperties cp1 =
            doc.BeginUpdateCharacters(doc.Paragraphs[1].Range);
        cp1.FontName = "Noto Sans";
        doc.EndUpdateCharacters(cp1);

        wordProcessor.SaveDocument(fileName, DocumentFormat.Docx);

        using var exportedPdf = new MemoryStream();
        wordProcessor.ExportToPdf(exportedPdf);
        exportedPdf.Position = 0;
        using var ouput = Console.OpenStandardOutput();
        exportedPdf.CopyTo(ouput);
        ouput.Flush();

        Log("Done.");
    }
}
