ReportDesignerDataSourceSettings Class

Contains settings that allow you to hide data source actions from the Field List panel (part of the Web End-User Report Designer).

Namespace: DevExpress.XtraReports.Web.ReportDesigner

Assembly: DevExpress.XtraReports.v22.2.Web.WebForms.dll

NuGet Package: DevExpress.Web.Reporting

public class ReportDesignerDataSourceSettings :
    PropertiesBase,
    IPropertiesOwner

Public Class ReportDesignerDataSourceSettings
    Inherits PropertiesBase
    Implements IPropertiesOwner

Library	Related API Members
.NET Reporting Tools	ASPxReportDesigner.SettingsDataSource
ASP.NET MVC Extensions	ReportDesignerSettings.SettingsDataSource

Remarks

The ReportDesignerDataSourceSettings contains settings that allow you to hide actions in the Field List.

The following image demonstrates actions available in the Field List panel:

web-designer-field-list-data-source-settings-enabled

The following code hides the Add Data Source button and UI elements that allow the user to change and delete the data source and queries in the Field List:

@using ReportWizardCustomizationServiceMvcExample.Models
@model ReportDesignerModel

<script type="text/html" id="instant-report">
    <svg viewBox="-2 -5 32 32" xmlns="http://www.w3.org/2000/svg" xmlns:xlink="http://www.w3.org/1999/xlink">
        <g id="Layer_1" transform="translate(-2, -5)" style="enable-background:new 0 0 32 32">
            <g id="Check">
                <polygon class="dxd-icon-fill" points="27,5 11,21 5,15 2,18 11,27 30,8  " fill="#727272" />
            </g>
        </g>
    </svg>
</script>

<script type="text/html" id="wizard-labels-page">
    <div class="dxrd-wizard-type-page dxrd-wizard-type-page-labels">
        <div class="page-title">Custom Wizard Page</div>
        <div class="dx-fieldset">
            <div class="dx-field">
                <div class="dx-field-label">Report Name</div>
                <div class="dx-field-value">
                    <div data-bind="dxTextBox: { value: label4Value }"></div>
                </div>
            </div>
            <div class="dx-field">
                <div class="dx-field-label">Label1: </div>
                <div class="dx-field-value">
                    <div data-bind="dxTextBox: { value: label1Value }"></div>
                </div>
            </div>
            <div class="dx-field">
                <div class="dx-field-label">Label2: </div>
                <div class="dx-field-value">
                    <div data-bind="dxTextBox: { value: label2Value }"></div>
                </div>
            </div>
            <div class="dx-field">
                <div class="dx-field-label">Label3: </div>
                <div class="dx-field-value">
                    <div data-bind="dxTextBox: { value: label3Value }"></div>
                </div>
            </div>
        </div>
    </div>
</script>

<link href="~/Content/reportWizardCustomization.css" rel="stylesheet" />

<script src="~/Scripts/reportWizardCustomization.js"></script>

@Html.DevExpress().ReportDesigner(settings => {
    settings.Name = "ReportDesigner1";

    settings.ClientSideEvents.CustomizeWizard = "CustomizeReportWizard";

    settings.SettingsDataSource.AllowAddDataSource = false;
    settings.SettingsDataSource.AllowEditDataSource = false;
    settings.SettingsDataSource.AllowRemoveDataSource = false;

    // Add the created data source to the list of default data sources.
    foreach (var dataSourceItem in Model.DataSources)
        settings.DataSources.Add(dataSourceItem.Key, dataSourceItem.Value);
    }).BindToUrl("TestReport").GetHtml()

public async Task<IActionResult> Designer(
    [FromServices] IReportDesignerClientSideModelGenerator clientSideModelGenerator,
    [FromQuery] string reportName) {
    Models.ReportDesignerCustomModel model = new Models.ReportDesignerCustomModel();
    model.ReportDesignerModel = await CreateDefaultReportDesignerModel(clientSideModelGenerator, reportName, null);
    model.ReportDesignerModel.DataSourceSettings.AllowAddDataSource = false;
    model.ReportDesignerModel.DataSourceSettings.AllowEditDataSource = false;
    model.ReportDesignerModel.DataSourceSettings.AllowRemoveDataSource = false;
    return View(model);
}

<dx-report-designer [reportUrl]="reportUrl" height="calc(100vh - 90px)">
    <dxrd-request-options [getDesignerModelAction]="getDesignerModelAction" [host]="hostUrl"></dxrd-request-options>
    <dxrd-designer-model-settings [allowMDI]="true">
        <dxrd-datasource-settings [allowAddDataSource]="false" [allowEditDataSource]="false" [allowRemoveDataSource]="false"></dxrd-datasource-settings>
    </dxrd-designer-model-settings>
    <dxrd-callbacks (CustomizeWizard)="OnCustomizeReportWizard($event)">
    </dxrd-callbacks>
</dx-report-designer>

The Field List with hidden actions is shown in the following image:

web-designer-field-list-data-source-settings-disabled
