PieSeriesLabelStyle Class

Stores the Pie series label appearance settings.

Declaration

public class PieSeriesLabelStyle
extends SeriesLabelStyle

Remarks

The following image shows label parameters to customize.

Inherited Members

java.lang.Object.equals(java.lang.Object)(Object)

Object.getClass()

java.lang.Object.hashCode()()

java.lang.Object.notify()()

java.lang.Object.notifyAll()()

java.lang.Object.toString()()

java.lang.Object.wait()()

java.lang.Object.wait(long)(long)

java.lang.Object.wait(long, int)(long,int)

getTextStyle()

setTextStyle(TextStyle)

Inheritance

Object

ChartElement

StyleBase

TextElementStyleBase

SeriesLabelStyle

PieSeriesLabelStyle

PieSeriesLabelStyle()

Initializes a new PieSeriesLabelStyle class instance with default parameters.

Declaration

public PieSeriesLabelStyle()

Methods

getConnectorThickness() Method

Returns the label connector thickness.

Declaration

public Float getConnectorThickness()

Returns

Type	Description
Float	The label connector thickness in pixels.

setConnectorThickness(Float) Method

Specifies the label connector thickness.

Declaration

public void setConnectorThickness(Float thickness)

Parameters

Name	Type	Description
thickness	Float	The label connector thickness in pixels.
